Welcome To Our Company!
Strip Cleaning Shot Blasting Machine
Strip Cleaning Shot Blasting Machine

Strip Cleaning Shot Blasting Machine

Price 25200.0 INR/ Unit

MOQ : 1 Unit

Strip Cleaning Shot Blasting Machine Specification

  • Usage
  • Fabrication, Foundry and Forging
  • Motor Type
  • 3 Phase Motor
  • Size
  • Standard
  • Product Type
  • Strip Cleaning Shot Blasting Machine
  • Weight
  • 5000 Kilograms (kg)
  • Color
  • Gray


Strip Cleaning Shot Blasting Machine Trade Information

  • Minimum Order Quantity
  • 1 Unit
  • FOB Port
  • Gujarat
  • Payment Terms
  • Cash in Advance (CID)
  • Supply Ability
  • 4 Units Per Month
  • Delivery Time
  • 2 Months
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Strech fil wrap
  • Main Export Market(s)
  • South America, Middle East, Africa, Central America, North America, Asia, Australia, Eastern Europe, Western Europe
  • Main Domestic Market
  • West India, North India, East India, Gujarat, Mizoram, Meghalaya, Manipur, Goa, Jharkhand, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Central India, Odisha, Punjab, Arunachal Pradesh, Tripura, Chhattisgarh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Rajasthan, Uttar Pradesh, Uttarakhand, West Bengal, Karnataka, Lakshadweep, Bihar, Chandigarh, Assam, Haryana, Himachal Pradesh, Nagaland, Sikkim, Tamil Nadu, Telangana, Pondicherry, All India, South India, Kerala, Andhra Pradesh, Daman and Diu
  • Certifications
  • MSME Registered Company and ISO Certified Company


About Strip Cleaning Shot Blasting Machine

Strip Cleaning Shot Blasting Machine Manufacturer in India Orbitech Shotblast LLP

Product Description

Orbitech Shotblast LLP is a manufacturer and supplier of Strip Cleaning Shot Blasting Machines in India, designed for continuous surface cleaning of metal strips used in fabrication, steel processing, foundry, forging, and industrial coating applications. This machine is suitable for manufacturers that require consistent surface preparation of moving metal strips before painting, powder coating, protective coating, or other downstream operations.

Unlike batch-type shot blasting machines that process individual components, a Strip Cleaning Shot Blasting Machine is designed around a continuous strip-feed arrangement. Metal strips pass through an enclosed blasting chamber while high-speed centrifugal blast wheels propel steel abrasive onto the moving surface. This process removes rust, mill scale, oxide layers, and other surface contaminants to improve surface cleanliness and prepare the material for subsequent processing.

Orbitech Shotblast LLP offers industrial strip cleaning solutions with a powered feeding arrangement, abrasive blasting wheels, a closed blasting chamber, abrasive recovery and separation equipment, and a dust collection system. The machine can be configured for different strip widths and production-line speeds according to material thickness, surface condition, and required cleaning results.

The Strip Cleaning Shot Blasting Machine is particularly useful for steel strip processors, metal service centres, fabrication companies, and manufacturers integrating surface treatment into a continuous production line. Its controlled abrasive-blasting process helps reduce dependence on manual cleaning and supports consistent treatment across the processed strip.

For businesses searching for a Strip Cleaning Shot Blasting Machine manufacturer in India or a Strip Cleaning Shot Blasting Machine supplier, Orbitech Shotblast LLP provides industrial equipment solutions for continuous metal surface preparation.

Advantages of Strip Cleaning Shot Blasting Machine

  • Continuous Strip Processing: Designed to clean moving metal strips without requiring separate batch loading for each workpiece.
  • Consistent Surface Preparation: Controlled abrasive projection helps achieve uniform cleaning across the strip surface.
  • Effective Rust Removal: Removes surface rust, oxide deposits, and mill scale from suitable metal strips.
  • Improved Coating Adhesion: Prepares metal surfaces for painting, powder coating, and protective coating applications.
  • Adjustable Line Speed: The feed rate can be selected according to the strip material, thickness, contamination level, and required finish.
  • Abrasive Recycling: A recovery and separation system allows reusable steel abrasive to circulate through the blasting process.
  • Reduced Manual Labour: Mechanized processing reduces reliance on manual brushing and grinding.
  • Production-Line Integration: Can be integrated with strip feeding, levelling, drying, coating, or other compatible production equipment.
  • Enclosed Blasting Operation: The enclosed chamber helps contain abrasive during the cleaning process.
  • Industrial-Duty Construction: Heavy-duty structural construction and replaceable wear liners support regular production use.

Key Features

  • Continuous strip-feed shot blasting arrangement.
  • Enclosed abrasive-blasting chamber.
  • Four centrifugal blast wheels in the assumed standard configuration.
  • 11 kW motor per blast wheel.
  • Adjustable strip feeding speed.
  • Strip inlet and outlet guides.
  • Abrasion-resistant chamber liners.
  • Steel shot and steel grit compatibility.
  • Mechanical abrasive collection and recovery system.
  • Bucket elevator for abrasive transportation.
  • Air-wash abrasive separator.
  • Industrial cartridge-type dust collection system.
  • Electrical control panel with operating controls and safety interlocks.
  • Inspection and maintenance access doors.
  • Suitable for integration with compatible coating and surface-treatment lines.
  • Customizable strip width and conveyor arrangement.

Applications and Usage

The Strip Cleaning Shot Blasting Machine is used in industrial processes where metal strips require continuous abrasive cleaning before further manufacturing or finishing.

1. Steel Strip Processing

Removes rust, mill scale, and oxide deposits from compatible steel strips before subsequent processing.

2. Fabrication Industry

Prepares strip material used in fabricated components, sheet-metal assemblies, supports, brackets, and industrial structures.

3. Foundry and Forging Support Operations

Supports the cleaning of compatible strip-form metal stock and related materials used in manufacturing operations.

4. Painting and Powder Coating Lines

Prepares the strip surface to support suitable coating application and adhesion.

5. Metal Service Centres

Helps prepare incoming or processed strip stock for customers requiring a cleaner surface finish.

6. Industrial Component Manufacturing

Suitable for strip material used in profiles, metal fittings, fabricated parts, and related products.

7. Steel Furniture and Equipment Manufacturing

Can be used to prepare compatible strip stock before forming, fabrication, and coating.

8. Continuous Production Lines

Suitable for plants that require strip cleaning as an integrated stage in an automated or semi-automated manufacturing process.

Working Principle

The Strip Cleaning Shot Blasting Machine uses centrifugal abrasive impact to clean metal strips moving continuously through an enclosed chamber.

  • Strip Feeding: The metal strip enters the machine through the inlet guide and feeding arrangement.
  • Controlled Movement: The strip advances through the machine at a selected line speed.
  • Abrasive Blasting: High-speed blast wheels propel steel shots or steel grits onto the strip surface.
  • Surface Cleaning: Abrasive impact removes rust, mill scale, oxide layers, and other loose contaminants.
  • Abrasive Collection: Used abrasive falls into the recovery section below the blasting chamber.
  • Abrasive Separation: The recovery system transports the abrasive through a separator that removes dust and broken particles before reuse.
  • Dust Extraction: The dust collector captures airborne contaminants generated during blasting.
  • Strip Discharge: The cleaned strip exits the machine and proceeds to inspection, coating, forming, or another production stage.

The final surface condition depends on the strip material, thickness, initial contamination, abrasive type, blast-wheel arrangement, and line speed.

Technical Specifications Strip Cleaning Shot Blasting Machine

The following is an assumed standard industrial configuration for product-description purposes. Values are practical estimates for this machine category and are not verified factory specifications.

Specification

Assumed Standard Configuration

Product Name

Strip Cleaning Shot Blasting Machine

Brand

Orbitech Shotblast LLP

Machine Type

Continuous Strip Shot Blasting Machine

Application

Metal Strip Cleaning and Surface Preparation

Industries

Steel Processing, Fabrication, Foundry and Forging

Machine Construction

Heavy-Duty Welded Steel Structure

Overall Dimensions (L W H)

4500 2200 3000 mm

Approximate Machine Weight

5000 kg

Standard Strip Width

300500 mm

Available Strip Width Configurations

50150 mm, 300500 mm, 600750 mm and 7501000 mm

Compatible Strip Material

Carbon Steel and Suitable Ferrous Metal Strips

Strip Thickness Range

1.510 mm

Number of Blast Wheels

4

Blast Wheel Motor Power

11 kW per wheel

Total Blast Wheel Power

44 kW

Blast Wheel Diameter

380 mm

Blast Wheel Speed

Approximately 2900 RPM

Strip Feed System

Motorized Roller Feed

Adjustable Line Speed

Up to 20 m/min, depending on configuration

Typical Operating Speed

310 m/min

Abrasive Type

Steel Shot and Steel Grit

Initial Abrasive Charge

Approximately 800 kg

Abrasive Flow Rate

Approximately 4 150 kg/min

Abrasive Recovery System

Mechanical Recovery with Bucket Elevator

Abrasive Separator

Air-Wash Type

Dust Collection System

Cartridge-Type Dust Collector

Dust Collector Airflow

Approximately 6000 m/hour

Total Installed Power

Approximately 55 kW

Power Supply

415 V, Three-Phase, 50 Hz

Control System

Electrical Control Panel with Safety Interlocks

Chamber Lining

Manganese Steel or Equivalent Wear-Resistant Lining

Inlet and Outlet

Strip Guides with Feeding and Discharge Arrangement

Surface Treatment

Rust, Mill Scale and Oxide Removal

Typical Cleaning Speed

Depends on strip condition and required surface finish

Machine Colour

Industrial Grey

Installation Type

Industrial Floor-Mounted

Listed Price on Product Page

25,200 per unit

Listed Price Range

35,00,00075,00,000 per unit

Minimum Order Quantity

1 Unit

Why Choose Orbitech Shotblast LLP?

Orbitech Shotblast LLP manufactures and supplies industrial shot blasting equipment for metal surface preparation. Its product range includes machines for continuous processing, component cleaning, and applications requiring controlled abrasive impact.

The Strip Cleaning Shot Blasting Machine is intended for production environments where strip material needs consistent cleaning before coating or further processing. Its continuous-feed design, centrifugal blast wheels, abrasive recovery arrangement, and dust collection system provide the main components needed for an industrial strip-cleaning process.

Orbitech Shotblast LLP serves customers looking for strip cleaning equipment suited to fabrication, steel processing, foundry, forging, and other metalworking operations. The machine configuration can be selected according to strip width, material thickness, line speed, and surface-cleanliness requirements.

Frequently Asked Questions (FAQs)

1. What is a Strip Cleaning Shot Blasting Machine?

A Strip Cleaning Shot Blasting Machine is an industrial machine that continuously cleans moving metal strips by projecting steel shots or steel grits onto the surface to remove rust, mill scale, oxide layers, and other contaminants.

2. What materials can be processed in this machine?

It is primarily designed for suitable ferrous metal strips, particularly carbon steel strips. Material compatibility should be assessed according to the strip composition, thickness, hardness, and required surface finish.

3. What is the purpose of shot blasting metal strips?

Shot blasting removes surface contaminants and creates a prepared surface for subsequent processes such as painting, powder coating, protective coating, and other manufacturing operations.

4. What strip width can the machine handle?

The assumed standard configuration accommodates strips approximately 300500 mm wide. Other configurations, including 50150 mm, 600750 mm, and 7501000 mm widths, can be considered for different production requirements.

5. What is the operating speed of a Strip Cleaning Shot Blasting Machine?

The assumed typical operating range is 310 metres per minute, with configurations designed for speeds up to 20 metres per minute. The actual achievable speed depends on strip condition, material thickness, blast-wheel power, and required cleanliness.

6. How many blast wheels are used in the machine?

The assumed standard configuration uses four centrifugal blast wheels, each powered by an 11 kW motor. The number and power of the wheels can vary with the strip width and production requirements.

7. Which abrasive media are suitable for strip cleaning?

Steel shots and steel grits are commonly used for ferrous metal strip cleaning. The selection depends on the required surface profile, contamination level, and downstream coating process.

8. Does the machine recycle abrasive media?

Yes. The assumed configuration includes a mechanical abrasive recovery system, bucket elevator, and air-wash separator to return reusable abrasive to the blasting circuit while removing dust and broken particles.

9. Can the machine be integrated into a painting or powder coating line?

Yes. A Strip Cleaning Shot Blasting Machine can be integrated with compatible feeding, handling, and coating-line equipment. The complete line layout depends on strip dimensions, processing speed, available space, and production requirements.

10. Where can I buy a Strip Cleaning Shot Blasting Machine in India?

You can contact Orbitech Shotblast LLP in Vadodara, Gujarat, India, for a Strip Cleaning Shot Blasting Machine for industrial metal strip surface preparation. The machine configuration can be selected according to strip width, line speed, cleaning requirements, and production-line layout.
